Feature

    ☆ Self-diagnostic
    ☆ Reed switch test
    ☆ Fire LED allows 360° viewing
    ☆ LED indication for both fire and normal status
    ☆ LED indication for normal status can be turned off by handheld
        programmer
    ☆ UL listed

Technical Specifications

    ☆ Operating Voltage: 24VDC
    ☆ Standby Current: ≤60μA
    ☆ Alarm Current: ≤55mA
    ☆ LED Indicatort:
        Red, periodically flash once inpolling when the status is set to
        "ON"; don't illuminate when thestatus is set to"OFF".
         Periodicallyflash twice in fault: illuminate inalarming.
    ☆ Remote indicator Output:
             Polarity-sensitive output ,Directly connecting with remote
             indicator (built in 10k resistor in series, maximum
             ouputcurrent is 2.0mA); The remote indicator does not
             illuminate innormal and flashes in alarm.
    ☆ Maximum Ripple Voltage: 2V( peak-to-peak)
    ☆ Alarm Reset: Instantaneous power down (Min.10sn,
        Max1.0VDC)
    ☆ Sensitivity: Diameter:
             Action Temperature:135F(57.2°C)
             Response rate of rise:15'F /min (8.3°0/min)
    ☆ Class and Setup:
             Class and Setup: Rate of rise and fixed temperature
             (default)and fixed temperature programmable.
    ☆ Maximum spacing: 50 ft.(15.2 m)
    ☆ UL Temperature Range: 32°F (0°C)- 100°F(37.8°C)
    ☆ Operating Temperature: 14°F(-10°C)-122°F(+50°C)
    ☆ Relative Humidity: s95%, non condensing
    ☆ Material of Enclosure: ABS White (RAL 9016)
    ☆ Ingress Protection Rating: IP2X
    ☆ Dimensions:
             Diameter:100mm
             Height: 53.3mm (with base)
    ☆ Mounting Hole Distance: 45mm-75mm
    ☆ Weight: 110g
