☆Loop powered.
   ☆Optical Pathway 5 -100 Meters.
   ☆Maximum monitoring area: 14 x100=1400m2
      Maximum width: 14m
   ☆Combination of the emitting and receiving part makes mounting easy and optical pathway accurate.
   ☆Built-in microprocessor enables intelligent judgment about fire alarm and fault.
   ☆Easy alignment and commissioning via supporting of onboard laser pointer and digital signal intensity indication.
   ☆Self-diagnostic function can monitor the internal fault.
   ☆Drift compensation for factors changing, such as a certain of dust accumulation, positional excursion, and ageing transmitter.

Technical Specifications

   ☆Operating Voltage: 24VDC (16V~28V)
     Commissioning current: ≤ 20mA
     Standby current: ≤ 2mA
     Alarm current: ≤ 5mA
   ☆Angle of Adjusting -6°to +6°
     Maximum angular misalignment ±0.5°
   ☆Sensitivity Level:
     Level 1: 1.3dB
     Level 2: 1.8dB (factory default)
     Level 3: 2.3dB
     Level 4: 2.8dB
   ☆Operating Environment:
    Temperature: -10°C - +50°C
    Relative Humidity≤ 95%, non -condensing
   ☆Ingress Protection Rating:
    IP20 without glue-seal
    IP66 through glue-seal treatment
   ☆Material and Color of Enclosure: ABS, gray
   ☆Dimensions: 206mm X 95mm X 95mm
   ☆Weight: 450g
