Feature

    ☆ Electronically addressed. The address can be modified in field
    ☆ Alarming by pressing, reset by a special key
    ☆ Plug-in structure
    ☆ Comply with UL38

Technical Specifications

    ☆ Operating Voltage: Loop 24V(16V~28V)
    ☆ Operating Current:
           Standby Current 0.6mA
           Alarm Current 1.8mA
    ☆ Indicator:
           Red.Flashes every 3s normally
           Steadily llluminates after alarm
    ☆ Type of Initiating Part: Reusable
    ☆ Initiating Mode: Pressing the action plate manually
    ☆ Resuming Mode: Manually resumed by a special key
    ☆ Programming Mode: Electronically addressed
    ☆ Address Range: Occupying one address, selectablewithin 1~242
    ☆ Wiring: Polarity-insensitive two-wire
    ☆ Ingress Protection Rating: lP43
    ☆ Environmental Temperature: 14°F(-10°C)~122°F(+50°C)
    ☆ Relative Humidity: ≤95%, non condensing
    ☆ Material of Enclosure: ABS
    ☆ Dimension (LxWxH): 87.1mmx87.1mmx58.5mm(with back box)
    ☆ Vounting Hole Distance: 60mm
    ☆ Weight: About 160g (with back box)
