Feature

    ☆ Receive message and send command (Reset,Silence, ACK
        etc.) through networkk
    ☆ Network interface: Optical Fiber
    ☆ 7.0"color TFT LCD
    ☆ Capacitive Touch screen
    ☆ History file 100,000 events capacity
    ☆ Password and key-protected nonvolatile memory
    ☆ User programmable password
    ☆ Field-programmable, or by pc with GST-DEF Defining Tool

Technical Specifications

    ☆ Input: 20VDC-28VDC
    ☆ Standby Current: 200mA
    ☆ Max.Current: 400mA
    ☆ Communication Distance: Maximum distance between two
        neighbor nodes is 20000m.
    ☆ Network Capacity: 250 nodes
    ☆ Display: 800x480,7.0"color TFT LCD
    ☆ Network: Optical Fiber
    ☆ Operating Environment: -5~50°C,≤93% RH,non-condensing
    ☆ Dimensions: 420mm(w)x350mm(H)x100mm(D)
