☆ Available for LPG, Natural Gas and Coal Gas
   ☆ Built-in 2 relay contacts
   ☆ Local buzzer alarm
   ☆ Alarm, Fault, Power indication
   ☆ Self-test button
   ☆ Electronically addressed

Technical Specifications

   ☆ Operating Voltage: 24V Loop, 24VDC Power Supply
   ☆ Operating Consumption:
               Standby: 0.5W
               Active: 3.0W
   ☆ Alarm Threshold:
               I-9602LW-LPG: 10%LEL(propane)
               I-9602LW-NG: 6%LEL(methane)
               I-9602LW-CG: 400×10^-6(hydrogen)
   ☆ Operating Environment:
           Temperature: -10℃ ～+50℃
           Relative Humidity: 95%, non condensing
   ☆ Dimensions: 121mm x 87mm x 57mm
